4 78-8125-3042-2-E
3M710-UMK25A Field Maintenance Kit (included with the 3M710-UTK25A Splicing Rig)
1. Cutter Blade
2. Error Tester Tool
3. Red Bridge Module Support
4. Gray Bottomless Splice Module
Support
5. 3mm Hex Wrench
6. Cleaning Brush
7. Hex Screws and Washers
8. Lubricating Grease
9. Thumb Screws
10. Kit Carrying Case
5
3
4
1
9
7
6
8
2
10
1.0 General Statement
The following Instructions show how to use the 3M
™
710 Splicing Rig for all splicing applications, including
blade replacement and optional accessories.
2.0 3M 710-UTK25A Splicing Rig and Field Maintenance Kit
3M 710-UTK25A Splicing Rig Parts
1. Handle Retaining Clip
2. Vertical Side Posts
3. Blade Retaining Screws (4 on the handle side, 2 on the
faceplate side)
4. “T” Bar Locking Knob
5. Splicing Rig Support Rod
6. Module Assembly Channel
7. Module Guides
8. Module “L” Clip
9. “L” Clip Release Knob
10. Color Code Guide
11. Cutter Blade Holder Assembly
12. Conductor Group Holder
13. Handle
14. Carrying/Operational Handle
15. Blade Guard
14
3
3
15
12
4
1
2
2
12
12
10
9
13
1
5
11
Body
“T” Bar
7
7
8
6
15
14
4
Faceplate
