3.0 Duplexing No Polish LC-JG1 Connectors
3.1 No Polish LC-JG1 can be duplexed without using extra parts. Two connectors can dovetail together to
form duplex connector
3.2 Identify dovetailing features on both sides of connector body
3.3 Dovetail two connectors to assemble them together
3.4 Make sure latches are fitting together
