InTouch Products
Food Services Trade Department
3M Commercial Care Division
3M Center, Building 551-1E-02
St. Paul, MN 55144-1000 19980615
#
##
#
Headset Intercom System
Model C960AA
Technical Bulletin 6/15/98
Headbands
The C960 headbands have been redesigned to be 0.375” smaller when they are adjusted to the
smallest setting. At the largest setting they will open to the same size as the original design. Only the
headband assembly, main (78-8095-0582-5) will change. The headband assembly, adjustable (78-8095-
0583-3) attached to the headset with a single screw, will not change. The new headbands can be
identified by 2 narrow raised stops on the swinging band directly below the adjusting tab. They are in
production and spare parts now. See drawing below:
Note 2 raised stops here
Headband, Main
78-8095-0582-5
Headband, Adjustable
78-8095-0583-3
(not changed)
0.375" smaller
