C5000 Installation Examples
The following two examples are intended to show an overview of typical C5000 Installations.
21 8 9
C1060
CAR WASH
FUEL
Critical Programming
Steps:
01: Selector ID = 1
03: Audio Channel = A
04: # Business = 1
DISPENSERS
WIRELESS A
CONTROLLER
C5000 1-Business Example
Critical Programming
Steps:
01: Selector ID = 2
03: Audio Channel = B
04: # Business = 1
Wired A
Wired B
21 8 9
LOOP
C96
0
(optional)
DRIVE THRU
SPKR #10
CAR WASH
FOOD FUEL
DISPENSERS
WIRELESS B
CONTROLLER
C5000 2-Business Example
Critical Programming
Steps:
01: Selector ID = 1
03: Audio Channel = A
04: # Business = 2
Critical Programming
Steps:
01: Selector ID = 2
03: Audio Channel = A
04: # Business = 2
Critical Programming
Steps:
01: Selector ID = 3
03: Audio Channel = B
04: # Business = 2
Wired A
Wired A
Wired B
