3M™ Multi-Touch Display User Guide
13
3M Touch Systems, Inc. Proprietary Information –
TSD-44310 REV B
640 x 480 60, 66, 72, 75
720 x 400 70
800 x 600 56, 60, 72, 75
832 x 624 75
1024 x 768 60, 70, 75
1152 x 864 75
1280 x 960 60
1280 x 1024 60, 75
1440 x 900 60, 75
1680 x 1050 60
1920 x 1080 60
Configuring the Display Settings
After you connect your Multi-Touch Chassis Display and turn on your computer, you
may need to configure one or more of these display settings. The ideal setting for the
Multi-Touch Chassis Display is as follows:
• Display mode (also called desktop area or video native resolution)
less than or equal to
1920 x 1080 resolution
• Refresh rate (also called vertical scan rate or vertical sync) 60 Hz
• Color depth (also called color palette or number of colors) at least 16-bit (high color)
Adjusting the Multi-Touch Chassis Video Display
This section provides guidelines for adjusting the video display and using the display
controls to adjust the image to your liking. The controls for adjusting the video display
are located on the back of the Multi-Touch Chassis Display. These buttons let you
display the on-screen menu and adjust the phase, image position, contrast, and brightness.
Before you make any adjustments:
• Be sure to adjust the controls in your normal lighting conditions.
• Display a test image or pattern whenever you adjust the video.
User Controls For On Screen Display
Your Multi-Touch Chassis Display has five controls for adjusting the video display.
MENU UP DOWN SELECT POWER
Key/OSD Menu Off Status Menu On Status
Menu Menu appear Menu disappear/return to main item
Up Brightness Main item select up/Adjust up
Down Contrast Main item select down/Adjust down
Select Enter/Select sub-item function
Power Power On/Off
