3M C860 - Connectors

To Next Page

To Previous Page

CHANNEL SELECT Switch

Programming Jack

RESET Switch

Selects base station operating channel.

For programming headsets/belt packs to the same channel as the base station.

For programming new channel selection or jumper setting(s) into the

microprocessor.

Connectors:

AUXILIARY Terminal Strip

An extra 4 terminals at the bottom of the right–hand terminal block.

Loop Detector Connector

Noise Reduction Connector (under left half–cover)

Main Page

Installation Instructions1
Table of Contents3
Typical Single Lane Installation5
Figure 1. Typical Installation5
Battery Charger6
Figure 2. Battery Chargers (3-Slot and 6-Slot Versions)6
