3
6. Reach between your legs and grasp the leg strap on your right side. Bring the strap up and insert the tab of the buckle
into the receptor of the buckle on the right side. You will hear a click when the tab engages properly.
7. Connect the right leg strap using the same procedure as in Step 6. To adjust the leg straps, unlock ( ) the webbing
lock on the quick connect buckle and pull on the strap. A plastic end keeper on the end of the strap will stop it from
pulling completely out of the buckle. When the strap is properly adjusted, lock ( ) the webbing lock.
To release the
buckle, press the silver-colored tabs on the buckle towards each other with one hand, while pulling on the tab portion of
the buckle with the other hand.
8. Adjust shoulder straps to a snug t using the strap adjustment procedure described between Steps 4 and Step 5 on
the following page. Left and right sides of the shoulder straps should be adjusted to the same length and the upper
front D-ring should be centered on your lower chest. The back D-ring should be centered between your shoulder
blades. Adjust the leg straps to a snug t. At least 3 in. (8 cm) of webbing must extend past the buckle on the leg
straps. Adjust the waist belt again as necessary for a secure, comfortable t.
;
See Section 2.2 for more information on using the buckles present on the ExoFit NEX Suspension Harness.
Figure 2 – Donning the Harness
Step 1 Step 2 Step 3 Step 4
Step 5 Step 6 Step 7 Step 8
