3M™ Multimedia Projector H10 Product Safety Guide
© 3M 200412
√ Note
Reset the lamp operation hours. See “Reset Lamp Hours” for details.
ENGLISH
3. Remove lamp module: Slowly pick up the lamp module by the handles. (4)
4. Insert lamp module: Carefully insert (4) the new lamp module. Ensure that it is fully seated.
Tighten the lamp module retaining screws (3) to secure the lamp module in place.
Optional Lamp: 78-6969-9693-9 (Contact 3M customer Service.)
Insert the hinge tabs on the bottom of the lamp access door, then close and tighten the retaining
screw (1) to secure the door.
(2) Lamp access door
(1) Screw
(2) Screws (4) Handles
To Next Page
