3rd Eye AWT09MLEDSD - Specifications

4
USER MANUAL
AWT09MLEDSD
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Specifications
ITEM
SPECIFICATION
Video
Input Level
1.0 Vp-p±10% Composite, 75 W Balanced
Video Standard
Support NTSC (525 lines) / PAL (625 lines)
Display Speed
NTSC
240fps
PAL
200fps
Display
Resolution
CVBS
720 x 480, 720 x 576
Monitor Output
Main
1.0Vp-p Composite, 75 W Balanced
Audio
LINE Input Level
x8 Audio Input @1Vp-p@20k W (include 1CH MIC)
Output Level
x1 -10dB 1K W
Display (TFT LCD)
Resolution
800 X 3 (RGB) X 480
Active area
198(W) X 111.70(H)mm
View angle
0 ∘
70
90 ∘
50
180 ∘
70
270 ∘
70
Luminance
550
Contrast ratio
500
