Multi-lane M8 Y cable
Use this cable when connecting a 9650SE-24M8 controller to
multi-lane-enabled drive backplanes that have SFF-8087 mini
SAS 4i connectors (Figure 9).
Figure 9. Multi-lane M8 Cable (SFF-8087)
Multi-lane M8 fanout cable
When connecting a 9650SE-24M8 controller to individual
SATA drives or a backplane that has individual SATA
connectors, use the Multi-lane M8 fanout cable. These cables
have an M8 connector on one end and eight individual SATA
connectors on the other end. They look similar to the Multi-lane
serial breakout cable shown in Figure 7, except that they have
eight individual connectors instead of four.
