Chapter 2. Installing Your 3ware RAID Controller
26 3ware 9650SE Serial ATA RAID Controller Installation Guide
Table 2: LED Indicator Pin Positions
Controller
LED
Header
Pin Pair Comment
9650SE-2LP J7 : : : : : Orientation Horizontal
0 1 : : All Port number/All
(all activity indicator)
k-cathode-minus is on the top
a-anode-plus is on the bottom
9650SE-4LPML J7 : : : : : Orientation Horizontal
0 1 2 3 All Port number/All
(all activity indicator)
k-cathode-minus is on the top
a-anode-plus is on the bottom
9650SE-8LPML J7 : : : : : Orientation Horizontal
0 1 2 3 All Port number/All
(all activity indicator)
J8 : : : : : Orientation Horizontal
4 5 6 7 All Port number / All
(All activity indicator)
k-cathode-minus is on the top
a-anode-plus is on the bottom
9650SE-12ML J7 : : : : : Orientation Horizontal
0 1 2 3 All Port number/All (All activity
indicator)
J8 : : : : : Orientation Horizontal
4 5 6 7 All Port number/All (All activity
indicator)
J9 : : : : : Orientation Horizontal
8 9 10 11 All Port number/All (all activity
indicator)
k-cathode-minus is on the top
a-anode-plus is on the bottom
