Installation Overview
www.3ware.com 31
Figure 22. Points of connection on the half-height controller
Figure 23. Points of connection on the full-height controller
b) BBU receptacle
c) Hole for posta) Slots for the clips
b) BBU receptacle
c) Hole for post
a) Hole and slots for the clips
