K-METRON Radio User Instructions (Firmware 3.0.4; Doc v4.0)
4 | P a g e
The Configuration Menu is navigated using the following buttons:
To SCROLL through the Menus, press X (or “Delete”).
To SELECT a Menu item, press the ORANGE TRIGGER.
2.3 The Measurement End of the Sensor Head
The measurement end of the sensor will attract the magnet. Ensure this end of the sensor is
in contact with the surface of the part to be measured.
2.4 Coupling the Sensor Head with the Calibrated Magnet.
Place the Sensor Head on one face of the product that is to be measured. Hold or place the
magnet on the opposite side of the product wall until it couples to the sensor head.
Hollow objects can be measured by inserting the calibrated magnet through a small opening
in the product. The magnet should immediately be coupled with the sensor head positioned
on the outside of the product and adjacent to the aperture. The sensor head can then be
slid over the surface of the product to the desired place of measurement. Movement should
be slow and steady. Care should be taken when moving the sensor head to avoid de-
coupling.
