2. Technical Specifications
Electrical Specifications
Description Minimum Nominal Maximum
Supply Voltage (VAC) 198 230 264
Supply Frequency (Hz) - 50Hz -
Load Current (A) - 13 16
Load Size (W) 250 3000 3200
Relay Contact Voltage (VAC) - - 250
Relay Contact Current (A) - - 16
Clamp Current (A) - - 100
Recommend PV System Size (kW) 2 - 15
Dimensions and weight
Width (mm) 150 Depth (mm) 64
Height (mm) 140 Weight (g) 935
5
