Know your product
1. Handle bar
2. Lower handle
3. 4 mounting knobs
4. Charger
5. Off-On Start Key Switch
6a Rear 180mm Wheel
6b Front 150mm Wheel
7. Catcher
8. Height adjustment lever
9. Fuel tank
10. Fuel tank cap
11. Oil filler cap
12. Recoil starter
13. Spark plug cap
14. Air filter
15. Handle bar locking lever
16. Discharge guard
17. 2 x Swing blades
18. Blade bolt
19. Spark plug spanner
20. Priming bulb
21. Carburettor fuel
bowl drain plug
22. Recoil starter eyelet
23.
Battery Connection
plug
24. Battery
