Know your product
1. On/off switch
2. Base
3. Mounting holes (x2)
4. Work table
5. Mitre gauge
6. Disc guard
7. Sanding disc
8. Sanding plate
9. Work support
10. Work support
hex screw
11. Sanding belt
12. Belt bed
13. Belt tracking knob
14. Belt tension lever
15. Belt bed locking screw
16. Table lock knob
9
11
12
3
2
45 1
10
76 8
11
13
14
15
16
