A-dec 500 Pre-Installation Guide
6 85.0052.00 Rev D
A-dec 511 Chair
Plan View with Elevation
27"
686 mm
51.5"
1306 mm
10.5" 267 mm
Range of Headrest
Width of Baseplate
Width of Backrest
25"
631 mm
63"
1600 mm
9" - 18.5"
229 - 470 mm
21"
533 mm
Forward Chair Travel
(from base down
to base up)
Space
Between
Arms
To Seat Pocket
To Seat Pocket
13.5"
343 mm
72"
1829 mm
11"
280 mm
34"
864 mm
80
º
9"
229 mm
57.5"
1461 mm
2.5"
64 mm
21.5"
546 mm
31.5"
800 mm
