3 Hydronic piping (continued)
DIR #2000577546
HOT WATER
SUPPLY
BOILER WATER
IN
TEMPERATURE
GAUGE
COLD WATER SUPPLY
BOILER WATER OUT
Figure 3-4 Water to Water Heat Exchanger Multiple Units
Please note that these illustrations are meant to show system piping concept only, the installer is responsible
for all equipment and detailing required by local codes.
NOTICE
Indirect Plate Water Heater Installation & Service Manual
