Size Description Unit BFC 80 BFC 100 BFC 120
A Overall height mm 2060 2060 2060
C Position on pallet mm 530 530 530
D Appliance diameter mm 850 850 850
E Depth mm 1000 1000 1000
F Width mm 900 900 900
G Diameter of flue gas
discharge
mm 130/200 130/200 130/200
H Height of flue gas
outlet/air supply
mm 1995 1995 1995
Hx x position flue gas
outlet
mm 310 310 310
Hy x position flue gas
outlet
mm 440 440 440
K Height of gas
connection
mm 1855 1855 1855
M Height of cold water
supply
mm 225 225 225
N Height of hot water
outlet
mm 2060 2060 2060
Ny y position of hot water
outlet
mm 205 205 205
P Height of cleaning
opening
mm 290 290 290
R Height of drain valve
connection
mm 225 225 225
S Height of T&P valve
connection
mm 1425 1425 1425
W Height of condensation
drain
mm 240 240 240
1 Cold water supply
connection (external)
-
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
2 Hot water outlet
(male)
-
R 1
1
/
2
R 1
1
/
2
R 1
1
/
2
3 Gas control valve
connection (external)
-
R
3
/
4
" R
3
/
4
" R
3
/
4
"
4 Drain valve connection
(internal)
-
3
/
4
"
3
/
4
"
3
/
4
"
5 T&P valve connection
(female)
- 1"-11.5 NPT 1"-11.5 NPT 1"-11.5 NPT
6 Cleaning/inspection
opening
mm 95 x 70 95 x 70 95 x 70
7 Condensation drainage
connection (female)
- Ø 40 Ø 40 Ø 40
