A.O. Smith cyclone BFC - 80 - Concentric Wall Flue Terminal Specs C13; Concentric Roof Flue Terminal Specs C33

Installation
30 Instruction manual BFC
3
is
Concentric wall flue terminal specifications C13
Concentric roof flue terminal specifications C33
Subject Description
Wall flue terminal set:
• 1x wall flue terminal (incl. wall flange &
clamping ring)
• 1x pipe 500mm
• 1x bend 90°
Item No. 0302 326
1
Construction Concentric
Manufacturer Muelink & Grol
Type M2000 MDV SEC
Pipe material Construction Concentric
Flue gas
discharge
Thick-walled aluminium with lip ring seal
Air supply Thin-walled galvanised sheet steel
Pipe diameters Flue gas
discharge
Ø 130mm
Air supply Ø 200mm
1
No other wall flue terminal is permitted. Use this item number to order the wall conduit set from supplier,
manufacturer or wholesaler.
Subject Description
Roof flue terminal set:
• 1x wall flue terminal (incl. clamping
ring)
• 1x pipe 1000mm
• 1x mounting flange
Item No. 0306 855
1
Construction Concentric
Manufacturer Muelink & Grol
Type M2000 DDV SEC
Pipe material Construction Concentric
Flue gas
discharge
Thick-walled aluminium with lip ring seal
Air supply Thin-walled galvanised sheet steel
Pipe diameters Flue gas
discharge
Ø 130mm
Air supply Ø 200mm
1
No other wall flue terminal is permitted. Use this item number to order the wall conduit set from supplier,
manufacturer or wholesaler.
