Aaeon AEC-6850 - Specifications

Embedded Controller AEC-6850
Chapter 1 General Information 1- 5
1.3 Specifications
System
 CPU: Intel
®
Celeron
®
M 600MHz/ 1.3GHz
Processor
 Construction: Rugged Aluminum Alloy chassis
 System Memory: DDR SODIMM x 1, Max. 512MB
 VGA: DB-15 VGA connector
 Keyboard/Mouse: PS/2 Keyboard & Mouse
 Ethernet: 10/100Base-TX RJ-45 connector x 1
 SSD: Internal Type II CompactFlash
™
slot x 1
 Card Reader: CompactFlash
™
, SD/ MMC/ MS/ XD
 Device Bay
(Optional):
CD-ROM & 2.5”HDD Kit, 2 x 2.5” HDD Kit,
3.5” HDD Kit
 Serial Port: 1 x RS-232, 1 x RS-232/422/485
 Audio: MIC / Line In / Line Out by expansion
cable
 USB: 3 USB 2.0 ports
 DVI: DVI connector x 1
 Watchdog Timer: Generate a time-out System reset, setting
via software
 Power Supply: A1/A2 Version—AC Input:
External Power Adapter; Input Voltage:
100V AC~240V AC @ 50 ~ 60Hz;
A3/A4 Version—DC Input: 9V DC~30V DC
