Chapter 2 Hard
ware Installation
2 - 7
2.7 CD-ROM and 2.5”
HDD Kit Ins
tallation
CD-ROM and 2.5” HDD
Kit Combination
S
tep 1: Get the disk bracket ready
.
S
tep 2: Fasten the CD-ROM to the disk bracket
w
ith screws.
