The most important aspect of troubleshooting unit ventilator controls is to isolate the source of
the problem into one of two categories:
1 The problem resides within the UVC.
2 The problem is external to the UVC. Under most circumstances the problem is external to
the UVC.
Alarm and Fault Monitoring
The UVC is programmed to monitor the unit for specific alarm conditions. If an alarm
condition exists, a fault occurs. When a fault exists, the following occurs:
• The UVC indicates the fault condition by displaying the fault code on the keypad/display.
• The remote wall-mounted sensor (optional) LED flashes a pattern indicating that a fault
condition exists.
• The fault signal binary output energizes.
• The fault performs the appropriate control actions as described for each fault.
Manual reset faults can be reset in one of three ways:
• By cycling the unit power.
• Via the keypad/display menu.
• Via the network interface.
Table 22: Alarm and fault code summary
Priority Fault description Reset
Keypad/
display fault
codes
1 Space Temp Sensor Failure Auto F0
2 DX Pressure Fault 2-Auto in 7 days, then Manual F1
3
Compressor Envelope Fault 2-Auto in 7 days, then
Manual*
F2
4 Discharge Air DX Cooling Low Limit Indication Auto F3
5 Condensate Overflow Indication Auto F4
6 Space Coil DX Temp Sensor Failure Auto F5
7 Outdoor Temp Sensor Failure Auto F6
8 Discharge Air Temp Sensor Failure Auto F7
9 Water Coil DX Temp Sensor Failure Auto F8
10 Water-out Temp Sensor Failure Auto F9
11 Space Humidity Sensor Failure Auto FA
12 Outdoor Humidity Sensor Failure Auto Fb
13 Space CO
2
Sensor Failure Auto FC
14 Not used Fd
15 Not used FE
16 Change Filter Indication Manual FF
17 EPROM Memory Indicator Replace conroller board EE
18 Configuration Display Download file --
* Rev 1_27 has auto reset
