AAP ESL KIT - HARDWARE INSTALLATION; Internal Cabinet Components; Keypad Back Removal

E16LED KP
Cable Entry Point
PCB fits here
17 volt AC
power leads
HARDWARE CONFIGURATION
Page 6
Screw PCB
down in
these points.
BATTERY
GOES HERE
WIRE 230V
MAINS IN
HERE.
INSIDE VEIW OF PLASTIC CABINET
POP OUT CABLE CLAMP FOR MAINS LEAD.
End view of
Keypad
Carefully slide a flat blade screwdriver
into slots to remove back.
Removing back from keypad.
CUT THIS SUPPORT OFF
