AAP ESL KIT - ESL CONNECTION DIAGRAMS; Telephone Line Integration Options; System Component Wiring; Power and Mains Connections

E16LED KP
RESISTOR COLOUR CODES:
2K2 = = RED, RED, RED, GOLD.
4K7 = = YELLOW, VIOLET, RED, GOLD.
8K2 = = GREY, RED, RED, GOLD.
SIREN
TAMPER
LED
STROBE
EOL
SS-1C
SATELLITE SIREN
ESL CONNECTION DIAGRAM
230V
AC
Input
Lin
Dat
Clk
Neg
Pos
Gnd 12V 1 C 2 3 C 4 Tmp Gnd
Outputs
Gnd 12V 1 2 3 4
ELITE S-LITE
V908.12
In
Lin
Out
AC
AC
Red
Blk
17VAC
Zone 1 Passive
Infra-Red Detector
0v
12v
EOL TAMPER EOL RELAY
2k2
Zone 2 Passive
Infra-Red Detector
0v
12v
EOL TAMPER EOL RELAY
2k2
HOUSE
PHONES
PHONE LINE
OFF THE
STREET
SILICONE FILLED CRIMPS
TELEPHONE WIRING OPTION 1: Standard analogue line
PIEZO
SIREN
2k2
2k2
P N
Keypad
Terminal Block
ON
12
0V
C
D
1
ANT
RX-16 MF349 v090618
(303, 433 & 915MHz)
Optional Radio Receiver Connects here:
PIR 2
PIR 1
INTERNAL
EXTERNAL
KEYPAD 1 RECEIVER
PHONE LINE
OFF THE
STREET
WITH ADSL ENABLED
ADSL MODEM
LINE
PHONE
DSL008
ADSL LINE FILTER
SILICONE FILLED CRIMPS
TELEPHONE WIRING OPTION 2: with high speed internet (broadband)
ADSL FILTER NOT SUPPLIED IN KIT
TELEPHONE WIRING OPTION 3: with Voice over IP System
IP-MODULE NOT SUPPLIED IN KIT
Internet Router
VoIP phone lines will Not work
with the Alarm System.
Internet Connection
IP-MODULE
Lin Dat Clk Neg Pos
12 Volt
SLA
Battery
