TABLE 1-4. METER CAPACITY VALUES
Meter
Size
Meter
Capacity*
Flow Ranges
0 to Value Tabulated
Minimum Maximum
inch mm gpm gpm L/min gpm L/min
1
2
15 26.4172 0.5 2.0 26.4 100.0
1 25 52.8344 1.06 4.0 52.8 200.0
1
1
2
40 158.503 3.17 6.0 158.0 600.0
m
3
/h m
3
/h
2 50 264.372 5.28 1.2 264.0 60.0
3 80 792.516 15.85 3.60 792.0 180.0
4 100 1056.68 21.14 4.80 1056.0 240.0
6 150 2641.72 52.84 12.0 2641.0 600.0
8 200 4755.09 95.11 21.6 4755.0 1080.0
10 250 7925.16 158.5 36.0 7925.0 1800.0
12 300 10566.8 211.4 48.0 10567.0 2400.0
* Each meter is calibrated to determine its flow capacity at a given velocity, which has been
established as 32.808 ft/s (10 m/s) for the Meter Capacity. The Meter Capacity expressed in gpm is
recorded on the meter nameplate.
All series 3000 meters are calibrated at 32.808 ft/s (10 m/s). Note that the display on the Signal
Converter supplied may read "Cal Factor" even when configured for 32.808 ft/s (10 m/s).
The Meter Capacity is the base upon which maximum and minimum limits for range
settings and outputs are established.
Flow Velocity can be determined as follows:
Meter Capacity:
Flow Velocity (ft/s) = (Operating gpm x 32.808)/Meter Capacity
NOTE
The maximum meter flow range is a function of the Signal
Converter used. The maximum flow range may exceed the meter
capacity to allow for overrange.
Series 10DX3000 Magnetic Flowmeter Instruction Manual
1-10
