Functionality IEC 61850 IEC 60617 ANSI
Frequency gradient DAPFRC df/dt> 81R
Overfrequency DAPTOF f> 81O
Underfrequency DAPTUF f< 81U
Load shedding LSHDPFRQ UFLS/R 81LSH
Transformer differential protection for 2-
winding transformers
TR2PTDF 3dI>T 87T
Fault locator SCEFRFLO FLOC 21FL
Distance protection DSTPDIS Z< 21, 21P, 21N
Automatic switch-onto-fault logic CVRSOF SOTF SOTF
Phase discontinuity PDNSPTOC I
2
/I
1
> 46PD
Three-phase current inrush detection INRPHAR 3I2f> 68
Circuit-breaker failure CCBRBRF 3I>/I
0
>BF 51BF/51NBF
Autoreclosing DARREC O → I 79
Tripping logic TRPPTRC I → O 94
Protection-related functions
Local acceleration logic DSTPLAL LAL LAL
Communication logic for residual
overcurrent
RESCPSCH CLN 85N
Scheme communication logic DSOCPSCH CL 85
Current reversal and WEI logic CRWPSCH CLCRW 85CRW
Current reversal and WEI logic for
residual overcurrent
RCRWPSCH CLCRWN 85NCRW
Control
Bay control QCCBAY CBAY CBAY
Interlocking interface SCILO 3 3
Circuit-breaker/disconnector control GNRLCSWI I ↔ O CB/DC I ↔ O CB/DC
Circuit breaker DAXCBR I ↔ O CB I ↔ O CB
Disconnector DAXSWI I ↔ O DC I ↔ O DC
Local/remote switch interface LOCREM R/L R/L
Synchrocheck SYNCRSYN SYNC 25
Supervision and monitoring
Circuit-breaker condition monitoring SSCBR CBCM CBCM
Fuse failure supervision SEQRFUF FUSEF 60
Current-circuit supervision CCRDIF MCS 3I MCS 3I
Trip-circuit supervision TCSSCBR TCS TCM
Generic measured values MVGGIO
Measured value limit supervision MVEXP
Station battery supervision SPVNZBAT U<> U<>
Tap position indication TPOSSLTC TPOSM 84M
Energy monitoring EPDMMTR E E
Table continues on next page
