- 14 -
UP/DOWN SCALE :
the value to which the output is
forced when a major fault occurs.
POLY COEFF. A0 (to A5) :
The coefficients of the
polynomial (in scientific notation and not for KSx)
FLANGE TYPE : The flange type
FLANGE MATERIAL : The flange material
O-RINGS : The material of the O-Rings
VENTS : The vents material
NUMBER OF REM.SEAL: the number of remote seal
REMOTE SEAL TYPE : The type of remote seal.
REMOTE SEAL FILL. : The remote seal filling liquid.
REM.SEAL ISOLATOR : The material of the remote
seal wetted diaphragm.
SENSOR FILL.FLUID : The filling fluid of the sensor.
SENSOR ISOL.MTL.: The diaphragm sensor's material.
MODEL TYPE : The transmitter model.
SENSOR RANGE : The sensor's range.
LOCAL ADJUSTMENT: Wheter the instrument is fitted
with Zero and/or Span calibration buttons or not.
LOCAL KEYS CONTROL: The local adjustments are
enabled or disabled
LCD DISPLAY MODE:
The variables displayed by the
LCD integral display.
H / W WRITE PROT. : Whether the configuration is
protected by the hardware jumper or not.
METER INST. : Whether the integral meter is installed
or not.
CALIBRATION TYPE : Standard or specific on operating
pressure or temperature or both.
PROCEDURE TYPE : Type of any special procedure
required for the manufacture of the sensor.
PRODUCT CODE : Transmitter's product code.
SEP. &/OR SERVICES : Code of remote seal or code
for special services or calibration.
MANIFOLD OR ORIFICE : Code of manifold or integral
orifice.
and in addition for 600T EN pressure transmitter
LONG TAG : Process or Plant identifier with a maximum
length of 24 characters.
PV BIAS VALUE : Value that can be applied to the
primary variable for scaling. It is stated in the same unit
of the primary variable.
SQR (x) CUT LINEAR : The connection point between
the linear line and square root line (from 10% to 20%).
OPERATIVE LRL : Low operative limit when PV BIAS
is active (when PV BIAS VALUE not equal to 0).
OPERATIVE URL : High operative limit when PV BIAS
is active (when PV BIAS VALUE not equal to 0).
DOUBLE POLY B0(to B2) - C0(to C2): The coefficients
of the double polynomial function (in scientific notation).
1ST POLY HIGH LIM. : Output percentage that identifies
the connection between the 1st and the 2nd polynomial
function of the Double Polynomial function.
and in addition for 652/653 S Temperature
METER OPTION : identifies if the transmitter is provided
with output meter (LCD or analog).
SENSOR TYPE : the type of the sensor element:
millivolt, thermocouple, resistance thermometer, ohms.
MEASUREMENT TYPE : single or diff. measurement.
CJC TEMPERATURE: constant cold junction
compensation value (-40°C to +135°C)
MULTIPLICAT. FACT: Multiplication factor for 100Ω
RTDs.
MAX TEMP FOR SENS.: Maximum temperature on
individual sensors for differential measurement.
TOTAL RESIST (Ohm) : Total cable resistance value.
CERTIFICATION TYPE : General purpose, intrinsic
safety, flame proof.
mA 100%: Output current at 100% range value.
mA 0% : Output current at 0% range value.
mA HLim : Output current upper limit.
Max: Maximum measured value
Min: Minimum measured value
mA LLim : Output current lower limit
SENSOR ERROR CONF. : Sensor error configuration.
SHORT V : Output current for short-circuited sensor.
OFF VAL : Output current for broken sensor.
TRANSMITTER VERSION : the version type of the
transmitter, 652S or 653S, head or integral mounted.
DIS (TRIBUTOR) : The name of the distributor.
