- 16 -
Information displayed under MATERIAL
( for Deltapi K pressure type only )
FLANGE TYPE : The flange type
FLANGE MATERIAL : The flange material
O-RINGS : The material of the O-Rings
VENTS : The vents material
NUMBER OF REM.SEAL: the number of remote seal
REMOTE SEAL TYPE : The type of remote seal.
REMOTE SEAL FILL. : the remote seal filling liquid.
REM.SEAL ISOLATOR : The material of the remote
seal wetted diaphragm.
SENSOR FILL.FLUID : The filling fluid of the sensor.
SENSOR ISOL.MTL.: The diaphragm sensor's material.
MODEL TYPE : The transmitter model.
SENSOR RANGE : The sensor's range.
NUTS AND BOLTS :
The material of the nuts and bolts.
.
PUSH BUTTONS: Wheter the instrument is fitted with
Zero and/or Span calibration buttons.
Information displayed under PRODuct DATA
( for KST Temperature Type only )
SENSOR TYPE : the type of the sensor element: millivolt,
thermocouple, resistance thermometer, ohms.
NUMBER OF WIRES : Two, three or four
LINEARIZATION MODE : linear with input or with
temperature.
MEASUREMENT TYPE : single or diff. measurement.
EXISTING TRIM : user, or factory calibration
UPPER TRIM POINT : the value of the upper trim point.
LOWER TRIM POINT : the value of the lower trim point.
TRIM POINT UNITS : the units used for the above
parameters.
CERTIFICATION TYPE : General purpose, intrinsic
safety, flame proof.
CONN. HEAD LENGTH : The length of the connection
head's extension.
BROKEN SENSOR DRIVE : Output driven >20 mA or
<4 mA if the sensor or the sensor connection breaks.
CAL. CERTIFICATE : Provided or not.
PUSH BUTTONS : Installed or not installed.
PRODUCT CODE : The transmitter's code number.
H/W WRITE PROT. Whether the configuration is
protected by the hardware straps.
FINAL ASSY NUMBER : the transmitter's final assembly
serial number.
Information displayed under MISCELLaneous
( for Deltapi K pressure transmitter only )
FINAL ASSY NUMBER : The transmitter's final assembly
serial number
P V SENSOR S/N : The sensor's module serial number
H / W WRITE PROT. : Whether the configuration is
protected by the hardware jumper.
METER INST. : Whether the integral meter is installed.
CALIBRATION TYPE : If std. or specific on operating
pressure or temperature or both
PROCEDURE TYPE : Type of any special procedure
required for the manufacture of the sensor.
PRODUCT CODE: Code of the Transmitter
SEP. &/OR SERVICES : Code of remote seal or code
for special services or calibration
MANIFOLD OR ORIFICE : Code of man. or int. orifice.
