APPENDIX "A1"
List of the allowed Sensor Types and relevant Units
for 652/653 S Temperature transmitter
Sensor Type Measuring Units
Ohms Ohms
Pt 100 Deg. C, Deg. F, Deg. R, Kelvin
Ni 100 Deg. C, Deg. F, Deg. R, Kelvin
Special RTD Deg. C, Deg. F, Deg. R, Kelvin
Millivolt mV
T/C Type B Deg. C, Deg. F, Deg. R, Kelvin
T/C Type E Deg. C, Deg. F, Deg. R, Kelvin
T/C Type J Deg. C, Deg. F, Deg. R, Kelvin
T/C Type K Deg. C, Deg. F, Deg. R, Kelvin
T/C Type L Deg. C, Deg. F, Deg. R, Kelvin
T/C Type N Deg. C, Deg. F, Deg. R, Kelvin
T/C Type R Deg. C, Deg. F, Deg. R, Kelvin
T/C Type S Deg. C, Deg. F, Deg. R, Kelvin
T/C Type T Deg. C, Deg. F, Deg. R, Kelvin
T/C Type U Deg. C, Deg. F, Deg. R, Kelvin
T/C Type W3 Deg. C, Deg. F, Deg. R, Kelvin
T/C Type W5 Deg. C, Deg. F, Deg. R, Kelvin
Special T/C Deg. C, Deg. F, Deg. R, Kelvin
APPENDIX "B"
List of the Primary Variable Units allowed
(600T Pressure Transmitter) :
inches H20 (20 deg C)
inches Hg (0 deg C)
feet H20 (20 deg C)
millimetres H20 (20 deg C)
millimetres Hg (0 deg C)
pounds / in ^2
bars
millibars
grams / centimeter^2
kilograms / centimeter^2
pascals
kilopascals
torr @ ( 0 deg C)
atmospheres
megapascal
inches H20 (4 deg C)
millimetres H20 (4 deg C)
List of the Primary Variable Units allowed
(652/653 S and KST Temperature Transmitter) :
Degrees Celsius
Degrees Fahrenheit
Degrees Rankine
Kelvin
millivolts
ohms
List of the allowed Measurement type for 652/653 S
Temperature transmitter
TC /(v)oltage (d)ifferential CJC (int)ernal
TC /(v)oltage (d)ifferential CJC (ext)ernal Pt100
TC /(v)oltage (d)ifferential CJC (ext)ernal Ni100
TC /(v)oltage (d)ifferential CJC constant (k)
RTD / ohm (d)ifferential 2 wires
TC /(v)oltage (s)ingle CJC (int)ernal
TC /(v)oltage (s)ingle CJC (ext)ernal Pt100
TC /(v)oltage (s)ingle CJC (ext)ernal Ni100
TC /(v)oltage (s)ingle CJC constant (k)
TC /(v)oltage (a)verage CJC (int)ernal
TC /(v)oltage (a)verage CJC (ext)ernal Pt100
TC /(v)oltage (a)verage CJC (ext)ernal Ni100
TC /(v)oltage (a)verage CJC constant (k)
RTD / ohm (s)ingle 2 wires
RTD / ohm (s)ingle 3 wires
RTD / ohm (s)ingle 4 wires
RTD / ohm (a)verage 2 wires
APPENDIX "A2"
List of the allowed Sensor Types and relevant Units
for KST Temperature transmitter
Sensor Type Measuring Units
Ohms Ohms
RTD - Pt 100, a = 385 Deg. C, Deg. F, Deg. R, Kelvin
RTD - Pt 100, a = 392 Deg. C, Deg. F, Deg. R, Kelvin
RTD - Pt 200, a = 385 Deg. C, Deg. F, Deg. R, Kelvin
RTD - Pt 500, a = 385 Deg. C, Deg. F, Deg. R, Kelvin
RTD - Ni 120 Deg. C, Deg. F, Deg. R, Kelvin
Special RTD Deg. C, Deg. F, Deg. R, Kelvin
Millivolt mV
T/C Type B NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type E NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type J NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type K NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type N BS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type R NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type S NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type T NBS Deg. C, Deg. F, Deg. R, Kelvin
T/C Type DIN J Deg. C, Deg. F, Deg. R, Kelvin
T/C Type DIN K Deg. C, Deg. F, Deg. R, Kelvin
T/C Type DIN S Deg. C, Deg. F, Deg. R, Kelvin
T/C Type DIN T Deg. C, Deg. F, Deg. R, Kelvin
Special T/C Deg. C, Deg. F, Deg. R, Kelvin
