Dimensions
253
1SVC 440 795 M0100
Figure 95: Dimensions CL-LMR/CL-LMT in mm
(specifications in inches see table 34)
Table 34: Dimensions in inches
90
102
110
M4
107.5
75 16.2516.25
47.5
56.5
58
45
4.5
mm inches mm inches
4.5 0.177 56.5 2.22
7.5 0.295 58 2.28
10.75 4.23 71.5 2.81
16.25 0.64 75 2.95
35.5 1.4 90 3.54
35.75 1.41 102 4.01
45
1.77 107.5 4.23
47.5 1.87 110 4.33
50 1.97
