ABB EBN861 - Current Consumption of EBN853; Current Consumption of EBN861; Fuses

7
7.2 Current Consumption of EBN853
Table 2
7.3 Current consumption of EBN861
Table 3
7.4 Fuses
1)
The 35 A fuse and the thermal safety cutout (16 A) are included in the scope of delivery. They ensure
safe operation for the special swiching conditions of power electronics EBN861. Note that the cable
cross-sectional area between the fuse and the electronics must be at least 2.5 mm
2
.
I
max
115 V I
max
230 V I
pos.
RHDE250-10 1.8 A 0.9 A each approx
40 .. 50% of I
max
RHDE500-10 2.2 A 1.1 A
RHDE800-10 3.4 A 1.7 A
RHDE1250-12 6.0 A 3.0 A
RHDE2500-25 4.8 A 2.4 A
RHDE4000-40 4.0 A 2.0 A
RHDE8000-80 4.0 A 2.0 A
RSDE10-5,0 3.4 A 1.7 A
RSDE10-10,0 3.8 A 1.9 A
RSDE20-5,0 4.8 A 2.4 A
RSDE20-7,5 3.8 A 1.9 A
RSDE50-3,0 4.0 A 2.0 A
RSDE100-1,5 4.4 A 2.2 A
I
max
230 V I
pos.
RHDE2500-10 5.3 A approx. 40 ... 50%
of I
max
RHDE4000-10 10.0 A
RHDE8000-15 9.0 A
RHDE16000-30 12.5 A
RSDE50-10,0 6.4 A
RSDE100-10,0 12.5 A
Electronic
unit
Fuse type Mounting site U = 115 V
U = 230 V
1)
EBN853 Series fuse external 16 A, slow
Mains fuse in connection chamber 12.5 A, slow 10 A, slow
Analogue setpoint input in connection chamber 40 mA; fast
Brake fuse power board 0.315 A, medium time-lag
Intermediate circuit fuse power board 10 A, super-quick
Anti condensation heater in connection chamber 2 A; slow
EBN861
Series fuses
1)
external
--
35 A fuse
16 A thermal
safety cutout
Brake fuse on board (power section)
--
0.315 A,
medium time-
lag
Intermediate circuit fuse power board
--
15 A, medium
time-lag
Anti condensation heater in connection chamber
(motor terminals)
2 A; slow
Table 4
