Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
Spare parts
12
Ordering spare parts
12.1
Page 118
September 2014 HZTL2498_EN Revision A
Required customer spare parts set (97070)
Quantity
Description
Part number
1 O-ring 42012
1
Gasket
42041
1 Gasket 42045
2 Verbus Ripp® Washer 42058
2
Hexagon-head screw
42059
3
Hexagon nut
61037
1 Spiral gasket 61050
12
Hexagon-head screw
61056
12 Verbus Ripp® Washer 61057
3 Verbus Ripp® Washer 61058
3
Hexagon-head screw
61059
1
Gasket
77005
1 O-ring seal (speed
sensor)
86506
Quantity
Description
Part number
1 O-ring 42012
1
Gasket
42041
1
Gasket
42045
15 Verbus Ripp® Washer 42058 / 42063 / 61043 / 61057 / 61058
15 Hexagon-head screw 42059 / 42064 / 61044 / 61056 / 61059
3 Hexagon nut 61037
1 Gasket 77005
1
O-ring seal (speed
sensor)
86506
TPL65-A32 / A33 / A36
TPL69-A32 / -A33
