Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
Disassembly and assembly
8
Module weights
8.2
Page 80
September 2014 HZTL2498_EN Revision A
Complete compressor casing
TPL65-A32 / A33 / A36
TPL69-A32 / -A33
Complete compressor casing 240 360
NOTICE
The total weight of the complete compressor casing is an addition of the
weights of the compressor casing, the diffuser and the wall insert.
Weight [kg]
