Operation Manual / A130-M.. - A145-M..
9 Dismantling and fitting / 9.1 Introduction
© Copyright 2022 ABB. All rights reserved. HZTL4031_EN Rev.P February 2022
9 Dismantling and fitting
9.1 Introduction
The precondition for the work described in the following is a turbocharger removed from the
engine (see chapter Removal and installation →30).
WARNING
Danger of burns
Touching hot surfaces or contact with hot operating fluids can cause burns.
u Do not touch hot surfaces. Observe the warning plate on the turbochar-
ger.
u Wear heat-resistant safety gloves and protective clothing.
u Wait for the turbocharger to cool down before carrying out any work.
Wear safety gloves to protect against thermal hazards.
WARNING
Cutting injuries when working on the turbocharger
Some parts on the turbocharger may have sharp edges. There is a risk of a
cutting injury.
u Wear safety gloves against mechanical risks when conducting assembly
and disassembly work.
Wear safety gloves to protect against mechanical hazards.
CAUTION
Further work
This Operation Manual may be used to carry out only the work described in
it. Further work that is carried out in an incorrect way can lead to serious
damage to the machine.
u Turbo Systems recommends having further work carried out only by
trained personnel from a Turbo Systems service station.
Tightening torques for assembly devices
Unless otherwise described, the screws and nuts of the assembly devices supplied by Turbo
Systems must be tightened in such a way that they are tight-fitting.
Oil orifice
u When disassembling the turbocharger, an oil orifice fitted in the oil inlet must not be re-
moved (see also chapter Removing the cartridge group).
