Operation Manual / TPL85-B14/-B15/-B16
Removal and installation
7
Remove the turbocharger
7.2
Page 87
© Copyright 2016 ABB. All rights reserved.
May 2016 HZTL2491_EN Revision B
WARNING
If support for the turbocharger is missing or defective when setting it
aside, the turbocharger could tip over and cause serious or even fatal
injuries.
 Support turbocharger at a suitable point.
 Cover oil connection.
