Operation Manual / TPL85-B14/-B15/-B16
Disassembly and assembly
8
Module weights
8.2
Page 92
© Copyright 2016 ABB. All rights res
erved.
May 2016 HZTL2491_EN Revision B
Compressor casing internal part assembly
TPL85-B
1630
NOTICE
The total weight of the complete internal part of the compressor casing
includes the internal part of the compressor casing, the diffuser and the
wall insert.
Weight [kg]
