Page #118 background image
Operation Manual / TPL65-A10 / -A30
12 Spare parts / 12.2 View of the turbocharger with part numbers
© Copyright 2020 . All rights reserved. HZTL2482_EN Rev.E March 2020
Part number Description
Cartridge group
51001 Gas inlet casing
56001 Nozzle ring
61001 Gas outlet casing
61036 Stud
61043 (in customer spare part
set)
Verbus Ripp® Washer
61044 (in customer spare part
set)
Hexagon-head screw
61056 (in customer spare part
set)
Hexagon-head screw
61057 (in customer spare part
set)
Verbus Ripp® Washer
61058 (in customer spare part
set)
Verbus Ripp® Washer
61059 (in customer spare part
set)
Hexagon-head screw
61037 (in customer spare part
set)
Hexagon nut
61076 (if provided) Centering bolt
61077 (if provided) Hexagon nut
63000 Turbine diffuser
68000 Foot
72000 Compressor casing
72018 Washer
72029 Stud
72027 Hexagon nut
77000 Wall insert
77005 (in customer spare part
set)
O-ring
77006 (in customer spare part
set)
O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
82000 Axial air suction branch
Page 116 / 117
