11 Requirements for installation and use in US and Canada
12.8 11.8 ETL marking and entities
— Conforms to UL 61010-1, UL 60079-0, UL 60079-1, UL 60079-11, UL 60079-15 and UL 60079-31
— Certified with CSA C22.2.61010-1, CSA C22.2.60079-0, CSA C22.2.60079-11, CSA C22.2.60079-15 and
CSA C22.2.60079-31
ETL approval Type of protection T4/T135 T4/T135 T5/T100 T6/T85
US
CL I, Zone 0 AEx ia IIC T6...T4 Ga
CL I, Div 1 GP ABCD T6...T4
CL II, Div 1 GP EFG T6...T4
When connected per DWG DH3260
-40°C<Ta<+85°C
Ui/Vmax= 30 Vdc
Ii/Imax= 100 mA
Pi/Pmax= 0.75 W
-40°C<Ta<+70°C
Ui/Vmax= 30 Vdc
Ii/Imax= 160 mA
Pi/Pmax= 1 W
-40°C<Ta<+40°C
Ui/Vmax= 30 Vdc
Ii/Imax= 100 mA
Pi/Pmax= 1,75 W
-40°C<Ta<+40°C
Ui/vmax= 30 Vdc
Ii/Imax= 50 mA
Pi/Pmax= 0.4 W
Canada
Ex ia IIC T6...T4 Ga
Ex ia IIIC T85°C...T135°C Da
When connected per DWG DH3260
US*
CL II, Div 1 GP EFG T6...T4
Zone 20 AEx ta IIIC T85°C...T135°C Da
-50°C<Ta<+85°C
Ui/Vmax = 30Vdc
Ii/Imax = 58 mA*
-50°C<Ta<+70°C
Ui/Vmax = 30Vdc
Ii/Imax = 95 mA*
-50°C<Ta<+40°C
Ui/Vmax = 30Vdc
Ii/Imax = 58 mA*
-50°C<Ta<+40°C
Ui/Vmax = 30Vdc
Ii/Imax = 28 mA*
Canada* Ex ta IIIC Tx Da IP67
US
CL I, Div 2 GP ABCD T6...T4
CL II, Div 2 GP FG T6...T4
CL I, Zone 1 AEx d IIC T6...T4 Gb
-40°C<Ta<+75°C
Ui/Vmax = 42Vdc
Ii/Imax = 100 mA
N/A
-40°C<Ta<+75°C
Ui/Vmax = 42Vdc
Ii/Imax = 100 mA
-40°C<Ta<+75°C
Ui/Vmax = 42Vdc
Ii/Imax = 100 mA
Canada
Ex d IIC T6...T4 Gb
Ex tb IIIC T85°C...T135°C Db
US
CL I, Zone 2 AEx nA IIC T6...T4 Gc
CL I, Div 2 GP ABCD T6...T4
-40°C<Ta<+75°C
Ui/Vmax = 42Vdc
Ii/Imax = 100 mA
-40°C<Ta<+70°C
Ui/Vmax = 30Vdc
Ii/Imax = 160 mA
-40°C<Ta<+40°C
Ui/Vmax = 42Vdc
Ii/Imax = 40 mA
-40°C<Ta<+40°C
Ui/Vmax = 42Vdc
Ii/Imax = 40 mA
Canada Ex nA IIC T6...T4 Gc
US
CL I, Div 2 GP ABCD T6...T4
CL I, Zone 2 AEx ic IIC T6...T4 Gc
When connected per DWG DH3260
-40°C<Ta<+75°C
Ui/Vmax= 42Vdc
Ii/Imax= 100 mA
Pi/Pmax= 1 W
-40°C<Ta<+70°C
Ui/Vmax= 30Vdc
Ii/Imax= 160 mA
Pi/Pmax= 1 W
-40°C<Ta<+40°C
Ui/Vmax= 42Vdc
Ii/Imax= 40 mA
Pi/Pmax= 1 W
-40°C<Ta<+40°C
Ui/Vmax= 42Vdc
Ii/Imax= 40 mA
Pi/Pmax= 1 W
Canada
Ex ic IIC T6...T4 Gc
When connected per DWG DH3260
*The current limitation is applicable only if the equipment is used only with the Ex ta type of protection (CL II Div 1 GP EFG T6...T4
and Zone 20 AEx ta IIIC T85°C…T135°C Da for US and Ex ta IIIC Tx Da IP67 for Canada)
