8.4.1 Process Supply Voltage

CAUTION!

The process supply voltage must be included in the earthing concept (e. g.

earthing of the minus pole).

8.4.2 Inputs

1 Example for connection input Ix

5V0

5V1

Example

CD522

Connection > Inputs

2019/11/153ADR024117M02xx, 11, en_US66
