41-973.5R
23
Type PM Line of Relays For Pilot Wire Monitoring
And Transferred Tripping
Figure 18: Internal Schematic of the Type PMG-13 Relay in the FT-32 case -
dc supply – for two-terminal lines.
Figure 19: Internal Schematic of the type PMG-13 Relay in the FT-32 case -
dc supply – for three-terminal lines.
Sub 3
184A499
Sub 4 184A658
