30
1MRS 750500-MUM
)HHGHU7HUPLQDODQG0DF KLQH 7HUPLQDO
Operator’s Manual
5(BB
*UHHQ/('LQGLFDWRU
Three different functions are embedded in the Ready LED indicator.
7DEOH *UHHQ/('LQGLFDWRUIXQFWLRQV
6WHDG\/('5($'<
Normal operation
• No internal faults
• Auxiliary voltage is available
%OLQNLQJ/(',5)
An internal relay fault (IRF) has occurred but the
auxiliary voltage is connected
• When an internal fault occurs, a message is
received in the assisting window, provided the
HMI/MIMIC panel is operative
• The IRF LED indicator is latching
OR
The terminal is in test mode
1RQDFWLYH/('2))
The auxiliary voltage supply to the terminal has
been disconnected.
Check that the auxiliary voltage is
disconnected before taking any further
action
!
