 ,QWHUORFNLQJ
Interlocking is used to inhibit the close or open command to a controllable object in
certain situations. The interlocking program of RE_ 54_ operates according to the
permission principle, i.e. any control operations not enabled by interlocking are
inhibited.
When an object is selected with the [select] button, the assisting window shows the
status of the interlocking program. The downmost LED of the programmable LED
indicators is reserved for the interlocking function.
7DEOH /('LQGLFDWRUIXQFWLRQV
1RQDFWLYH/('2))
Neither interlockings nor active control test mode
%OLQNLQJ/('UHG
Control test mode active (interlocking bypass)
6WHDG\/('\HOORZ
Control command has been inhibited (interlocked or blocked)
