1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
47
1) These ranges are supported only in the feeder terminal revisions of the Release 2.5 or later.
7DEOH 0HDVXUHPHQWUDQJHV
3DUDPHWHU 9DOXHV 'HIDXOW
Voltage range 0 = 0...1V 0...1 V
1 = 0...5 V
2 = 1...5 V
3 = 0...10 V
4 = 2...10 V
5 = -5...5 V
6 = -10...10 V
Current range 0 = 0...1 mA 0...1 mA
1 = 0...5 mA
2 = 1...5 mA
3 = 0...10 mA
4 = 0...20 mA
5 = 4...20 mA
6 = -1...1 mA
7 = -2.5...2.5 mA
8 = -5...5 mA
9 = -10...10 mA
10 = -20...20 mA
Resistance range 0 = 0...100 0...100
1 = 0...200
2 = 0...500
3 = 0...1000
4 = 0...2000
5 = 0...5000
6 = 0...10000
Temperature
range
0 = Pt100 -45...150 °C Pt100 -45..150 °C
1 = Pt100 -45...600 °C
2 = Pt250 -45...150 °C
3 = Pt250 -45...600 °C
4 = Pt1000 -45...150 °C
5 = Pt1000 -45...600 °C
6 = Ni100 -45...150 °C
7 = Ni100 -45...250 °C
8 = Ni120 -45...150 °C
9 = Ni120 -45...250 °C
10 = Ni250 -45...150 °C
11 = Ni250 -45..250 °C
12 = Ni1000 -45...150 °C
13 = Ni1000 -45...250 °C
14 = Cu10 -45...150 °C
15 = Ni120US -45..150 °C
1)
16 = Ni120US -45..250 °C
1)
