ABB REF 545 Product Guide

Feeder Terminal REF 541, REF 543, REF 545.
1MRS750443-MBG
70
1) This function is only supported in the feeder terminal
revisions of Release 2.0 or later
COIND2 COIND2 I<->O IND2 Switching device 2 indication
COIND3 COIND3 I<->O IND3 Switching device 3 indication
COIND4 COIND4 I<->O IND4 Switching device 4 indication
COIND5 COIND5 I<->O IND5 Switching device 5 indication
COIND6 COIND6 I<->O IND6 Switching device 6 indication
COIND7 COIND7 I<->O IND7 Switching device 7 indication
COIND8 COIND8 I<->O IND8 Switching device 8 indication
COLOCAT COLOCAT I<->O POS Logic-controlled control position selector
COPFC
1)
55 COPFC Power factor controller
COSW1 COSW1 SW1 On/off switch 1
COSW2 COSW2 SW2 On/off switch 2
COSW3 COSW3 SW3 On/off switch 3
COSW4 COSW4 SW4 On/off switch 4
MMIALAR1 ALARM1 ALARM1 Alarm channel 1, LED indicator
MMIALAR2 ALARM2 ALARM2 Alarm channel 2, LED indicator
MMIALAR3 ALARM3 ALARM3 Alarm channel 3, LED indicator
MMIALAR4 ALARM4 ALARM4 Alarm channel 4, LED indicator
MMIALAR5 ALARM5 ALARM5 Alarm channel 5, LED indicator
MMIALAR6 ALARM6 ALARM6 Alarm channel 6, LED indicator
MMIALAR7 ALARM7 ALARM7 Alarm channel 7, LED indicator
MMIALAR8 ALARM8 ALARM8 Alarm channel 8, LED indicator
MMIDATA1 MMIDATA1 MMIDATA1 MIMIC data monitoring point 1
MMIDATA2 MMIDATA2 MMIDATA2 MIMIC data monitoring point 2
MMIDATA3 MMIDATA3 MMIDATA3 MIMIC data monitoring point 3
MMIDATA4 MMIDATA4 MMIDATA4 MIMIC data monitoring point 4
MMIDATA5 MMIDATA5 MMIDATA5 MIMIC data monitoring point 5
Table 23: Control functions
Function ANSI device
no.
IEC symbol Description
Table 24: Condition monitoring functions
Function ANSI device
no.
IEC symbol Description
CMBWEAR1 CB wear1 CB wear1 Circuit-breaker electric wear 1
CMBWEAR2 CB wear2 CB wear2 Circuit-breaker electric wear 2
CMCU3 MCS 3I MCS 3I Supervision function of the energizing current input circuit
CMGAS1 CMGAS1 GAS1 Gas pressure monitoring
CMGAS3
1)
CMGAS3 GAS3 Three-pole gas pressure monitoring
CMSCHED CMSCHED SCHED Scheduled maintenance
CMSPRC1 CMSPRC1 SPRC1 Spring charging control 1
CMTCS1 TCS1 TCS1 Trip circuit supervision 1
CMTCS2 TCS2 TCS2 Trip circuit supervision 2
CMTIME1 TIME1 TIME1 Operate time counter 1 for the operate time used (e.g. motors)
CMTIME2 TIME2 TIME2 Operate time counter 2 for the operate time used (e.g. motors)
CMTRAV1 CMTRAV1 TRAV1 Breaker travel time 1
CMVO3 MCS 3U MCS 3U Supervision function of the energizing voltage input circuit
