ABB REF 545 - Configuration, setting and SA system tools

1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
95
• Technical data corrections
• New virtual channels
• New type of RTD input: Ni 120US
)XQFWLRQEORFNV
• NOC3Low and NEF1Low: addition of ANSI inverse time curve
• Modification of Diff3
• New protection functions:
For further information about the changes above, refer to the function block
descriptions on the CD-ROM Technical Descriptions of Functions (1MRS 750889-
MCD).
3URWRFROVFRPPXQLFDWLRQ
• IEC 60870-5-103
• SMS bus
• parallel communication and support
• simultaneous use of the rear connectors
+DUGZDUHPHFKDQLFV
• Voltage threshold for digital inputs:
• power supply (PS1/240 V High) 110/120/220/240 V ac or 110/125/220 V dc
with the digital input nominal voltage 220 V dc
7RROV
• Protocol selections (“Protocol 2”)
 &RQILJXUDWLRQVHWWLQJDQG6$V\VWHPWRROV
The following tool versions are needed to support the new functions and features of
Release 2.5 revisions of the REF 54_:
• CAP 505 Relay Product Engineering Tools; CAP 505 v. 2.2.0-1
• CAP 501 Relay Setting Tools; CAP 501 v. 2.2.0-1
• LNT 505 LON Network Tool; LNT 505 v. 1.1.1-1
• LIB 510 Library for MicroSCADA v. 8.4.4; LIB 510 v. 4.0.4-2
)XQFWLRQ 'HVFULSWLRQ
CUB3Cap Three-phase current unbalance protection for H-bridge connected shunt
capacitor
Fusefail Fuse failure supervision
