18. Technical data
Table 7. Dimensions
Description Value
Width 220 mm
Height 177 mm (4U)
265.9 mm (6U)
Depth 249.5 mm
Weight box 6.2 kg (4U)
5.5 kg (6U)
1)
Weight LHMI 1.0 kg (4U)
1) Without LHMI
Table 8. Power supply
Description
600PSM03 600PSM02
U
aux
nominal 100, 110, 120, 220, 240 V AC, 50 and 60 Hz 48, 60, 110, 125 V DC
110, 125, 220, 250 V DC
U
aux
variation 85...110% of U
n
(85...264 V AC) 80...120% of U
n
(38.4...150 V DC)
80...120% of U
n
(88...300 V DC)
Maximum load of auxiliary voltage supply 35 W
Ripple in the DC auxiliary voltage Max 15% of the DC value (at frequency of 100 Hz)
Maximum interruption time in the auxiliary DC
voltage without resetting the protection relay
50 ms at U
aux
Power supply input must be protected by an
external miniature circuit breaker
For example, type S282 UC-K.
The rated maximum load of aux voltage which is given as 35 watts. Depending on the voltage
used, select a suitable MCB based on the respective current. Type S282 UC-K has a rated
current of 0.75 A at 400 V AC.
