Table 123. Supported functions
Function WebHMI PCM600
Parameter setting ● ●
Disturbance handling ● ●
Signal monitoring ● ●
Event viewer ● ●
Alarm LED viewing ● ●
Hardware configuration - ●
Signal matrix - ●
Graphical display editor - ●
IED configuration templates - ●
Communication management - ●
Disturbance record analysis - ●
IED user management - ●
User management - ●
Creating/handling projects - ●
Graphical application configuration - ●
IEC 61850 communication configuration, including GOOSE - ●
IED Compare - ●
25. Supported ABB solutions
ABB’s 630 series protection and control protection relays
together with the Grid Automation controller COM600
constitute a genuine IEC 61850 solution for reliable power
distribution in utility and industrial power systems. To facilitate
and streamline the system engineering ABB’s relays are
supplied with connectivity packages. The connectivity
packages include a compilation of software and relay-specific
information such as single-line diagram templates, manuals
and a full relay data model including event and parameter lists.
With the connectivity packages, the relays can be readily
configured via the PCM600 Protection and Control IED
Manager and integrated with the Grid Automation controller
COM600 or the MicroSCADA Pro network control and
management system.
The 630 series relays offer support for the IEC 61850 standard
including horizontal GOOSE messaging. Compared to
traditional hard-wired, inter-device signaling, peer-to-peer
communication over a switched Ethernet LAN offers an
advanced and versatile platform for power system protection.
Among the distinctive features of the protection system
approach, enabled by the full implementation of the IEC 61850
substation automation standard, are fast communication
capability, continuous supervision of the protection and
communication system's integrity, and an inherent flexibility
regarding reconfiguration and upgrades
At substation level, COM600 uses the logic processor and data
content of the bay level devices to enhance substation level
functionality. COM600 features a Web-browser based HMI
which provides a customizable graphical display for visualizing
single line mimic diagrams for switchgear bay solutions. To
enhance personnel safety, the Web HMI also enables remote
access to substation devices and processes. Furthermore,
COM600 can be used as a local data warehouse for technical
documentation of the substation and for network data collected
by the devices. The collected network data facilitates extensive
reporting and analyzing of network fault situations using the
data historian and event handling features of COM600.
COM600 also features gateway functionality providing
seamless connectivity between the substation devices and
network-level control and management systems such as
MicroSCADA Pro and System 800xA.
Generator Protection and Control
1MRS757583 C
Product version: 1.3
ABB 61
