Table 59. Three-phase overvoltage protection (PHPTOV) main settings
Parameter Function Value (Range) Step
Start value PHPTOV 0.05...1.60 pu 0.01
Time multiplier PHPTOV 0.05...15.00 0.01
Operate delay time PHPTOV 0.40...300.000 s 0.10
Operating curve type
1)
PHPTOV Definite or inverse time
Curve type: 5, 15, 17, 18, 19, 20
1) For further reference, see the Operation characteristics table
Table 60. Three-phase undervoltage protection (PHPTUV)
Characteristic
Value
Operation accuracy At the frequency f = f
n
±1.5% of the set value or ±0.002 × U
n
Start time
1)2)
U
Fault
= 0.9 × set
Start value
Typically 24 ms (±15 ms)
Reset time <40 ms
Reset ratio Depends of the set
Relative hysteresis
Retardation time <35 ms
Operate time accuracy in definite time mode ±1.0% of the set value or ±20 ms
Operate time accuracy in inverse time mode
±5.0% of the theoretical value or ±20 ms
3)
Suppression of harmonics DFT: -50 dB at f = n × f
n
, where n = 2, 3, 4, 5,…
1)
Start value
= 1.0 × U
n
, Voltage before fault = 1.1 × U
n
, f
n
= 50 Hz, undervoltage in one phase-to-phase with nominal frequency injected from random phase angle
2) Includes the delay of the signal output contact
3) Minimum
Start value
= 0.50 × U
n
,
Start value
multiples in range of 0.90...0.20
Table 61. Three-phase undervoltage protection (PHPTUV) main settings
Parameter
Function Value (Range) Step
Start value PHPTUV 0.05...1.20 pu 0.01
Time multiplier PHPTUV 0.05...15.00 0.01
Operate delay time PHPTUV 0.040...300.000 s 0.010
Operating curve type
1)
PHPTUV Definite or inverse time
Curve type: 5, 15, 21, 22, 23
1) For further reference, see the Operation characteristics table
Generator Protection and Control
1MRS757583 C
Product version: 1.3
ABB 37
