Table 83. Low voltage ride through protection function (LVRTPTUV) main settings
Parameter Function Value (Range) Step
Voltage start value LVRTPTUV 0.05...1.20 pu 0.01
Num of start phases LVRTPTUV Exactly 1 of 3
Exactly 2 of 3
Exactly 3 of 3
-
Voltage selection LVRTPTUV Highest Ph-to-E
Lowest Ph-to-E
Highest Ph-to-Ph
Lowest Ph-to-Ph
Positive Seq
-
Active coordinates LVRTPTUV 1...10 1
Voltage level 1 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 1 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 2 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 2 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 3 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 3 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 4 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 4 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 5 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 5 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 6 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 6 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 7 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 7 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 8 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 8 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 9 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 9 LVRTPTUV 0.00...300.00 s 0.01
Voltage level 10 LVRTPTUV 0.00...1.20 pu 0.01
Recovery time 10 LVRTPTUV 0.00...300.00 s 0.01
Generator Protection and Control
1MRS757583 C
REG630
Product version: 1.3
ABB 43
